Li-ion Battery
LFP
Yes
Medium
25.6V
100ah
Availability: | |
---|---|
Features
• Ultra-reliable Lithium Iron Phosphate (LiFePO4) technologyGeneral Information | |
Battery Type | LiFePO4(Lithium Iron Phosphate) |
Nominal Voltage | 25.6V |
Nominal Capacity | 100Ah@25ºC,C10 |
Nominal Energy | 2560Wh@25ºC,C10 |
Operation Voltage | 20~29.2V |
Operation Temperature | Charge: 0°C - 45°C | Discharge: -20°C - 60°C |
Cycle Life @ 100%DOD | >3000 cycles (2560Wh@25ºC,C10) |
Cycle Life @ 80%DOD | >4000 cycles (2048Wh@25ºC,C10) |
Cycle Life @ 50%DOD | >6000 cycles (1280Wh@25ºC,C10) |
Dimension | 532*207*215mm (W x D x H) |
Terminal Type | M8 |
Weight | 24 kg |
Warranty Period | 5 years |
Environment Protection | IP56 |
BMS/Charge/Discharge | |
Charge Voltage Max | 25.6V |
Discharge Cut-off Voltage | 20V |
Charge Current Max | 100A |
Discharge Current Max | 100A continues |
200A burst (10 seconds) | |
Self-discharge Rate | <2% per month |
Protection | Over-charge protection |
Over-discharge protection | |
Over current protection | |
Cell balancing function | |
Over temperature protection |
BMS/Charge/Discharge
Charge Voltage Max: 29.2V
Discharge Cut-off Voltage: 20V
Charge Current Max: 30A
Discharge Current Max: 30A continues 60A burst (10seconds)
Self-discharge Rate: <2% per month
Protection
Over-charge protection
Over-discharge protection
Over current protection
Cell balancing function
Over temperature protection
