110kg
5years
6000times
| Battery module specification | |
| Battery Type | LiFePO4(Lithium Iron Phosphate) |
| Configuration | 16S2P-Prismatic 100Ah cell |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 200Ah |
| Nominal Energy | 10.24KWh |
| Operation Voltage | 46.4V-57.6V |
| Max discharge/charge current | 100A @25ºC |
| Operation Temperature | Charge: 0°C - 45°C | Discharge: -20°C - 55°C |
| Internal resistance | ≤30mΩ @AC 1kHz |
| Dimension | 1100*520*195 mm |
| Commnication Port | RS485/CAN |
| Weight | about 100kg |
| Warranty Period | 3 years/5 years |
| Environment Protection | IP21 |
| Certificate | UN38.3/MSDS/CE |
| Inverter Specification | |
| AC input | 220V/230Vac(customized) |
| AC input voltage range | APL Generator mode:90Vac-280Vac; Mains mode:170Vac 280Vac |
| AC Mains charging current | Max 60A |
| AC mains charging efficiency | >95% |
| Conversion time (bypass vs. inverter | 10mS |
| Output voltage waveform | Pure sine wave |
| AC output rated voltage | 230Vac |
| Rated output power | 5000W |
| Peak power | 10000W |
| Max efficiency | 92% |
| No-load power consumption | ≤50W |
| PV input voltage range | 60-145Vdc |
| Max PV input current | 50A |
| Max PV output current | 4400W |
| Max PV charge current | 80A |
| Rated battery input voltage | 48V |
| Battery voltage range | 40Vdc-60Vdc |
| WIFI module | Optional |
| Certificate | CE/EN61000 |
| Self-discharge Rate | Over-charge protection Over-discharge protection Over current protection Cell balancing function Over temperature protection |
Why choose us
Q1: Do you accept sample order?
A: Yes, we welcome sample to test the quality, customized is available.
Q2: What will be the delivery time after I place the order?
A: For mass order will take 15-30 days, it depends on the order quantity. For sample will take around 1 week.
Q3: Who will deliver our goods?
A: The products delivered by express, airline and sea shipping is avaiable, you can choose the most suitable delivery way. Also if you have your own forwarder just pass it to us, we will follow it up.
Q4: Can I print my company logo on the products?
A: Yes. We can provide OEM service.
Q5: : What will be the payment terms?
A: We accept T/T, Paypal, Money Gram etc.
Q6: What is your Warranty Policy?
A: We offer 5 years warranty for our products and can be replaced with new ones for free if quality Issues. Using Lithium iron phosphate battery, which has high safety performance, long cycle life, with service life of more than 10 years.
Q7: How to choose a right battery?
A: Just tell us your demand, then we will recommend a suitable battery to you.
| Battery module specification | |
| Battery Type | LiFePO4(Lithium Iron Phosphate) |
| Configuration | 16S2P-Prismatic 100Ah cell |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 200Ah |
| Nominal Energy | 10.24KWh |
| Operation Voltage | 46.4V-57.6V |
| Max discharge/charge current | 100A @25ºC |
| Operation Temperature | Charge: 0°C - 45°C | Discharge: -20°C - 55°C |
| Internal resistance | ≤30mΩ @AC 1kHz |
| Dimension | 1100*520*195 mm |
| Commnication Port | RS485/CAN |
| Weight | about 100kg |
| Warranty Period | 3 years/5 years |
| Environment Protection | IP21 |
| Certificate | UN38.3/MSDS/CE |
| Inverter Specification | |
| AC input | 220V/230Vac(customized) |
| AC input voltage range | APL Generator mode:90Vac-280Vac; Mains mode:170Vac 280Vac |
| AC Mains charging current | Max 60A |
| AC mains charging efficiency | >95% |
| Conversion time (bypass vs. inverter | 10mS |
| Output voltage waveform | Pure sine wave |
| AC output rated voltage | 230Vac |
| Rated output power | 5000W |
| Peak power | 10000W |
| Max efficiency | 92% |
| No-load power consumption | ≤50W |
| PV input voltage range | 60-145Vdc |
| Max PV input current | 50A |
| Max PV output current | 4400W |
| Max PV charge current | 80A |
| Rated battery input voltage | 48V |
| Battery voltage range | 40Vdc-60Vdc |
| WIFI module | Optional |
| Certificate | CE/EN61000 |
| Self-discharge Rate | Over-charge protection Over-discharge protection Over current protection Cell balancing function Over temperature protection |
Why choose us
Q1: Do you accept sample order?
A: Yes, we welcome sample to test the quality, customized is available.
Q2: What will be the delivery time after I place the order?
A: For mass order will take 15-30 days, it depends on the order quantity. For sample will take around 1 week.
Q3: Who will deliver our goods?
A: The products delivered by express, airline and sea shipping is avaiable, you can choose the most suitable delivery way. Also if you have your own forwarder just pass it to us, we will follow it up.
Q4: Can I print my company logo on the products?
A: Yes. We can provide OEM service.
Q5: : What will be the payment terms?
A: We accept T/T, Paypal, Money Gram etc.
Q6: What is your Warranty Policy?
A: We offer 5 years warranty for our products and can be replaced with new ones for free if quality Issues. Using Lithium iron phosphate battery, which has high safety performance, long cycle life, with service life of more than 10 years.
Q7: How to choose a right battery?
A: Just tell us your demand, then we will recommend a suitable battery to you.
