Li-ion Battery
LFP
Yes
Features
• Ultra-reliable Lithium Iron Phosphate (LiFePO4) technology
• Integrated battery management System (BMS)
• Ultra-long cycle life
• Light weight & compact
• Water & dust resistant (IP56)
• Highly durable ABS enclosure
• Drop-in lead acid replacement
• Environment friendly
• Bluetooth App is optional
| General Information | |
| Model | MC-RV24250 |
| Nominal Voltage | 25.6V |
| Nominal Capacity | 250Ah@25ºC,C10 |
| Nominal Energy | 6400Wh@25ºC,C10 |
| Battery Type | LiFePO4(Lithium Iron Phosphate) |
| Case Type | Metal |
| Dimension | 600(L)*220(W)*230(H) |
| Operation Voltage | 20~28.4V |
| Max. Discharge Current | 200A continuous |
| Operation Temperature | Charge: 0°C - 45°C Discharge: -20°C - 60°C |
| Cycle Life 100%DOD | >3000 cycles (6400Wh25ºC,C10) |
| Cycle Life 80%DOD | >4000 cycles (5120Wh25ºC,C10) |
| Weight | Approx 58kg |
| Warranty | 5Years |
| BMS/Charge/Discharge | |
| Charge Voltage Max | 28.4V±0.2V |
| Discharge Cut-off Voltage | 20V |
| Charge Current Max | 80A |
| Discharge Current Max | 80A (150A 10S) |
| Self-discharge Rate | <2% per month |
| Protection | Over-charge protection Over-discharge protection Over current protection Cell balancing function Over temperature protection |
Why choose us
Features
• Ultra-reliable Lithium Iron Phosphate (LiFePO4) technology
• Integrated battery management System (BMS)
• Ultra-long cycle life
• Light weight & compact
• Water & dust resistant (IP56)
• Highly durable ABS enclosure
• Drop-in lead acid replacement
• Environment friendly
• Bluetooth App is optional
| General Information | |
| Model | MC-RV24250 |
| Nominal Voltage | 25.6V |
| Nominal Capacity | 250Ah@25ºC,C10 |
| Nominal Energy | 6400Wh@25ºC,C10 |
| Battery Type | LiFePO4(Lithium Iron Phosphate) |
| Case Type | Metal |
| Dimension | 600(L)*220(W)*230(H) |
| Operation Voltage | 20~28.4V |
| Max. Discharge Current | 200A continuous |
| Operation Temperature | Charge: 0°C - 45°C Discharge: -20°C - 60°C |
| Cycle Life 100%DOD | >3000 cycles (6400Wh25ºC,C10) |
| Cycle Life 80%DOD | >4000 cycles (5120Wh25ºC,C10) |
| Weight | Approx 58kg |
| Warranty | 5Years |
| BMS/Charge/Discharge | |
| Charge Voltage Max | 28.4V±0.2V |
| Discharge Cut-off Voltage | 20V |
| Charge Current Max | 80A |
| Discharge Current Max | 80A (150A 10S) |
| Self-discharge Rate | <2% per month |
| Protection | Over-charge protection Over-discharge protection Over current protection Cell balancing function Over temperature protection |
