Li-ion Battery
LFP
Yes
Medium
40A
2A
Mainly focusing on different voltage and capacity for Li-ion lifepo4 battery cells and packs,
like 3.2V 6V 12V 24V 36V 48V 72V volt and capacity from 3Ah to 1000Ah.
At the same time,we also allow some customers propose different requirement and able to satisfy them.
| Items | Parameter | |
| Battery model | LPF6020T | |
| Nominal voltage | 60V | |
| Minimum capacity | 20Ah@25ºC | |
| Charging voltage | 69.35V | |
| Discharging cut-off voltage | 47.5V | |
| Standard charging | 0.2C /69.35V | |
| Max charging | 1C /69.35V | |
| Standard discharging | 1C/47.5V | |
| Max discharging | continuous discharge | 1C/47.5V |
| non-continuous discharge | 2C/47.5V | |
| Recommend Motor Application | 1000W~1500W | |
| Operating temperature | Charging: 0°C ~ 45°C | |
| Discharging: -20°C ~60°C | ||
| Storage (At 50% SOC and specified temp, recoverable capacity in % vs time ) | -10ºC~25ºC | (12 months ≥85% ) |
| -10ºC ~45ºC | (6 months ≥85% ) | |
| -10ºC~55ºC | (1 month ≥90% ) | |
| 20±5ºC is the recommended storage temperature | ||
| Visual Inspection | There should not be any remarkable scratches, cracks, bolts, cauterization, deformations, swelling, leakage and so on the surface of the cell. | |
| Warranty | 3 year | |
Mainly focusing on different voltage and capacity for Li-ion lifepo4 battery cells and packs,
like 3.2V 6V 12V 24V 36V 48V 72V volt and capacity from 3Ah to 1000Ah.
At the same time,we also allow some customers propose different requirement and able to satisfy them.
| Items | Parameter | |
| Battery model | LPF6020T | |
| Nominal voltage | 60V | |
| Minimum capacity | 20Ah@25ºC | |
| Charging voltage | 69.35V | |
| Discharging cut-off voltage | 47.5V | |
| Standard charging | 0.2C /69.35V | |
| Max charging | 1C /69.35V | |
| Standard discharging | 1C/47.5V | |
| Max discharging | continuous discharge | 1C/47.5V |
| non-continuous discharge | 2C/47.5V | |
| Recommend Motor Application | 1000W~1500W | |
| Operating temperature | Charging: 0°C ~ 45°C | |
| Discharging: -20°C ~60°C | ||
| Storage (At 50% SOC and specified temp, recoverable capacity in % vs time ) | -10ºC~25ºC | (12 months ≥85% ) |
| -10ºC ~45ºC | (6 months ≥85% ) | |
| -10ºC~55ºC | (1 month ≥90% ) | |
| 20±5ºC is the recommended storage temperature | ||
| Visual Inspection | There should not be any remarkable scratches, cracks, bolts, cauterization, deformations, swelling, leakage and so on the surface of the cell. | |
| Warranty | 3 year | |
