48V 100ah Sodium ion Battery Golf Cart Na+ Ion Battery

Longer cycle life - Up to 15 times longer cycle life and 5 times longer float/calendar life than lead-acid batteries.
More capacity - Provides up to 100% of usable energy.
Lightweight - 60% lighter than lead-acid batteries.
Low temperature capability - The battery operates across a −40℃ to +60℃ discharge temperature range, making it particularly attractive for outdoor equipment and cold-climate applications
High discharge rate – Ability to fully discharge the battery at a high rate of discharge.
Fast charging - Charges much faster than conventional sealed lead-acid batteries.
Long cycle life – More than 6000 cycles at 80% depth of discharge.
Intelligent BMS – The battery management system monitors and adapts to battery conditions to maximize performance and safety.

Price: $ 700

Discount Price: $ 569

Type:
Sodium Ion Battery
Connection Mode:
Series and Parallel
Rechargeable:
Chargeable
Discharge Rate:
Medium Discharge Rate
Size:
Medium
Accessories Type:
Battery

Availability:

Product Description

48V 100Ah Sodium ion Battery Common Customization:

Sodium-ion battery 48V 100Ah is a high-power battery pack designed for light electric vehicles (LEVs), golf carts, utility vehicles, AGVs, material-handling equipment, and other 48V industrial applications.

Engineered for frequent cycling and demanding environments, the SIBBAT-48100 delivers 125A continuous discharge, up to 300A pulse discharge, a specified 6,000+ cycle life, and discharge operation down to −40°C. An integrated smart BMS, CAN 2.0 and RS485 communications, and an IP67 enclosure make it ready for OEM equipment integration.

golf cart battery with LCD(1)

golf cart battery test

Nominal voltage		48V
Nominal capacity at 5 hours rate (25°C)		100Ah
Energy		4800Wh
Charge Efficiency at 0.2C (25°C)		99.50%
Discharge Efficiency at 1C (25°C)		96-99%
Approx. internal resistance (25°C)		≤100.0 mΩ
Cycle life / 0.2C 100% D.O.D		>6000 cycles ≥80% of initial capacity
Capacity affected by temperature	40°C	101%
	25°C	100%
	0°C	90%
	-10°C	75%
Mechanical
Dimensions	Length	492.0mm
	Width	366.0mm
	Height	232.2.0mm
	Total height	245.2mm
Terminal type
Colour		grey
Weight		~46.0kg
Water & Dust resistance		IP67
Battery Cell		NaCP50160118 (NFPP)
Cell strings		16 strings
Temperature
Nominal operating temperature		25°C±3 (77±5°F)
Operating temperature range	Discharge	-40°C~60°C(-40°F~140°F)
	Charge	-10°C~45°C (14°F~113°F)
	Storage	0°C~40°C (32°F~104°F)
Charging
Charging voltage at 25°C		55.2±0.2V
Standardchargemode(25°C±2°C,<75%RH)		0.2CA Constant Current to 55.2V, then Constant Volt- age 55.2V until the current drops to 0.02CA. Rest 30 minutes, before use.
Nominal charging current		100A
Maximum charging current		200A
Charging cut-off voltage		55.20V
Discharging
Continuous discharge current		125A
Maximumpulsedischargecurrent(<100ms)		300A（1S）
Discharge cut-off voltage		24V
Self discharge rate (25°C)		≤3%/month
Comunication & connection
Communication protocol (optional)		CAN/RS485
Bluetooth (optional)

Detailed Photos
