Li-ion Battery
Lithium-Ion Battery Pack
Yes
Medium
36V
Li-ion
Availability: | |
---|---|
Specification General Information | |
Battery Type | Li-ion |
Nominal Voltage | 36V |
Nominal Capacity | 4.4Ah 25ºC,C10 |
Nominal Energy | 158.4 Wh 25ºC,C10 |
Operation Voltage | 2.85-4.25 V |
Operation Temperature | Charge: 0°C - 55°C | Discharge: -20°C - 60°C |
Cycle Life 100%DOD | >3000 cycles (158.4Wh 25ºC,C10) |
Cycle Life 80%DOD | >4000 cycles (126Wh 25ºC,C10) |
Cycle Life 50%DOD | >6000 cycles (79Wh 25ºC,C10) |
Terminal Type | M6 |
Weight | 1.3KG |
Warranty Period | 5 years |
Environment Protection | IP65 |
OEM ODM | Acceptable |
Warranty | 5 Years |
BMS/Charge/Discharge | |
Charge Voltage Max | 42 V |
Discharge Cut-off Voltage | 28 V |
Charge Current Max | 4.4A |
Discharge Current Max | 13.2 A burst (10 seconds) |
Self-discharge Rate | <2% per="" month=""> |
Protection | Over-charge protection Over-discharge protection Over current protection Cell balancing function Cell balancing function Over temperature protection |
Company Profile
MICA POWER Co., Ltd. was founded in 2009 is a leading supplier in lithium battery solution in China. focusing on Lithium Polymer, Lithium ion & Lithium iron phosphate/LiFePO4 technology batteries and energy storage solutions. Our management team has more than 15 years' experience in battery business.
Facility Aare: 15000 square meters;
Employee: 1000.
We specialize in manufacturing and exporting lithium-polymer batteries, lithium-ion batteries, LiFePo4 rechargeable batteries, rechargeable batteries for 3C consumer electronics, AGV, RV/ caravan, marine, motorcycle, golf cart / trolly, UPS, solar storage, medical, clean machine, industrial, commercial use, etc with reliable and safety solution.
We also support customers with an outstanding service and a customized POS concept.
Our products have UL, CE, KC, PSE, RoHS, UN38.3 certificated and exported worldwide like Europe,North America, South America, Africa, Middle East and South-east Asia.
Specification General Information | |
Battery Type | Li-ion |
Nominal Voltage | 36V |
Nominal Capacity | 4.4Ah 25ºC,C10 |
Nominal Energy | 158.4 Wh 25ºC,C10 |
Operation Voltage | 2.85-4.25 V |
Operation Temperature | Charge: 0°C - 55°C | Discharge: -20°C - 60°C |
Cycle Life 100%DOD | >3000 cycles (158.4Wh 25ºC,C10) |
Cycle Life 80%DOD | >4000 cycles (126Wh 25ºC,C10) |
Cycle Life 50%DOD | >6000 cycles (79Wh 25ºC,C10) |
Terminal Type | M6 |
Weight | 1.3KG |
Warranty Period | 5 years |
Environment Protection | IP65 |
OEM ODM | Acceptable |
Warranty | 5 Years |
BMS/Charge/Discharge | |
Charge Voltage Max | 42 V |
Discharge Cut-off Voltage | 28 V |
Charge Current Max | 4.4A |
Discharge Current Max | 13.2 A burst (10 seconds) |
Self-discharge Rate | <2% per="" month=""> |
Protection | Over-charge protection Over-discharge protection Over current protection Cell balancing function Cell balancing function Over temperature protection |
Company Profile
MICA POWER Co., Ltd. was founded in 2009 is a leading supplier in lithium battery solution in China. focusing on Lithium Polymer, Lithium ion & Lithium iron phosphate/LiFePO4 technology batteries and energy storage solutions. Our management team has more than 15 years' experience in battery business.
Facility Aare: 15000 square meters;
Employee: 1000.
We specialize in manufacturing and exporting lithium-polymer batteries, lithium-ion batteries, LiFePo4 rechargeable batteries, rechargeable batteries for 3C consumer electronics, AGV, RV/ caravan, marine, motorcycle, golf cart / trolly, UPS, solar storage, medical, clean machine, industrial, commercial use, etc with reliable and safety solution.
We also support customers with an outstanding service and a customized POS concept.
Our products have UL, CE, KC, PSE, RoHS, UN38.3 certificated and exported worldwide like Europe,North America, South America, Africa, Middle East and South-east Asia.
