Mica Hot Selling Factory Customized 48V 100ah LiFePO4 Lithium Ion Battery Back Rechargeable Solar Storage System 51.2V

Type:
Lithium-Ion Battery Pack
Connection Mode:
Series Connection
Rechargeable:
Chargeable

Availability:



Inquire Add to Basket

Product Description

Features
• Ultra-reliable Lithium Iron Phosphate (LiFePO4) technology
• Integrated battery management System (BMS)
• Ultra-long cycle life
• Light weight & compact
• Water & dust resistant (IP56)
• Highly durable ABS enclosure
• Drop-in lead acid replacement
• Environment friendly
• Bluetooth App is optional

General Information
Model	MC-RA48100
Nominal Voltage	48V
Charging Voltage	100Ah@25ºC
Charging Voltage	54.6V
Discharging Cut-off Voltage	39V
Standard Charging	0.2C /54.6V
Max Charging	1.0C /54.6V
tandard Discharging	1C/39V
Communication	CAN/RS485/RS232
Operation Voltage	39V~54.6V
Operation Temperature	Charge: 0°C - 45°C Discharge: -20°C - 60°C
Cycle Life 100%DOD	>3000 cycles (6400Wh25ºC,C10)
Cycle Life 80%DOD	>4000 cycles (5120Wh25ºC,C10)
Cycle Life 50%DOD	>6000 cycles (3840Wh25ºC,C10)
Warranty	5Years

BMS/Charge/Discharge
Charge Voltage Max	58.4V
Discharge Cut-off Voltage	40V
Charge Current Max	50A
Discharge Current Max	100A continues 200A burst (10seconds)
Self-discharge Rate	<2% per month
Protection	Over-charge protection Over-discharge protection Over current protection Cell balancing function Over temperature protection

Why choose us

More than 15 Years' Experience in Lithium Battery
Mica Power Co. Ltd was established in 2009. Our management team has more than 15 years' experience in rechargeable battery. Our factory covers an area of 15,000 square meters and has more than 500 employees.

Benefit From Our Advantages
Backed by professional supporting team, we have expertise in R&D, OEM production and marketing. With the support of a professional and dedicated engineering and operation team, we are available to bringing customers' idea into reality. Flexible to customized request, such as sound adjusted, color, package, and accessories adjusted, so you can enjoy our quick one-stop OEM service.

Meeting Quality Standards
Our company has passed ISO 9001:2015 quality and BSCI system approval and our products have got the ROHS, CE, UL, IEC, UN38.3 certifications. The battery products have the advantages of high energy density, high power density, small volume, light weight,long service life, low self-discharge, flexible and varied shapes, safety performance and so on.

1,Q: What's the main product in Mica?
A: Rechargeable LiFePO4 battery, Li-ion, Lipo battery and power battery pack.

2,Q: Do you have any protection for battery pack?
A: Over-charge protection Over-discharge protection
Over current protection
Cell balancing function
Over temperature protection

3,Q: What is over discharge?
A: After charge, test the batteries' initial state. When the batteries are normal, discharge to 0V at 0.5C. Observe changes in battery appearance

4. Q: Can I have a sample order?
A: Yes, we accept sample order to test and check quality. Batteries can be made as require.

5. Q: Do you have MOQ limit?
A: Yes, we have MOQ limit for mass production, but it depends on battery model. Please contact us for details.

6. Q: How about the lead time?
A: Samples will takes 5-7 business days. Mass production will takes 25-30 days. It depends on quantity.

7. Q: How about shipping and delivery time?
A: Generally, battery will be shipped via Express, such as DHL, TNT, FedEx and UPS, delivery time is 3-5 business days. Or DDP service, delivery time is 11-15 business days. Airline and sea shipping also available.

8. Q: What about after-sale service?
A: We will offer you 1-5 year guarantee. If there are any problems, please inform us, we will offer you positive solutions.
